PORTABLE CNC LASER CUTTING MACHINE gantry laser cnc For AD advertising metal logo processing
Grilles decoration sheet metal laser cutting #cnclasercutter
Recommend Portable Light Gantry Laser cutting machine(TOPLOONG control system) :
Model X , JAX (MAX 's son)1200W , BT220 Manual focus cut head, $3980
Model A, MAX1500W BT220 Manual focus cut head, $4780
Model B, MAX 2000W BT220 Manual focus cut head, $5980
Model C, MAX 3000W BM110 Autofocus cut head, $7780
Optional:
Cut head BT220 upgrade to BM110 add $480,
Add 6 support leg $300,
Add Dust cover $300,
Add Spliced table $500.
| Motor Type | LEAD SHINE SERVO |
| Condition | New |
| Place of Origin | Anhui, China |
| Weight (KG) | 800 KG |
| Warranty | 2 years |
| Key Selling Points | High Productivity |
| Applicable Industries | Garment Shops, Building Material Shops, Construction works |
| Showroom Location | United States, Germany, Philippines, Peru, Saudi Arabia, Mexico, Spain, Morocco, Algeria, Sri Lanka |
| Marketing Type | Hot Product 2021 |
| Machinery Test Report | Provided |
| Video outgoing-inspection | Provided |
| Warranty of core components | 2 years |
| Core ComponentsCore Components | Bearing, Pump, Gear, Motor, Gearbox, PLC, Pressure vessel, Engine |
| Dimensions | 3000*1500MM |
| Brand Name | TOPLOONG |
| Model Number | 1530 /1630 /2430 /2030 /2060 |
| Voltage | 380V/220V |
| Rated Power | 10-50KW |
| Dimension(L*W*H) | 3.7*2.25*1.7 m |
| Year | 2019 |
| Cutting mode | FIBER LASER |
| Product name | CNC Plasma Metal Cutting Machine |
| Application | Sheet Metal Industry |
| Name | CNC FIBER LASER CUTTER |
| Type | Metal Cutting Tools |
| Function | Cutting Steel Cnc LASER Cutter |
| Cutting material | Metal .alloy Metal .aluminum.stainless Steel |
| Keywords | RAYTOOLS RAYCUS MAX LEADSHINE HKC |
| Cutting thickness | 0-150mm |
| Control system | Toploong+ RAYTOOLS |
| motor | Servo |
Cut thickenss Gas options 1200W(220v single phase):
1. >13bar air compressor (cut carbon steel 0.3-4mm , stainless steel,aluminum 0.3-4mm)
2. oxygen cylinder (cut carbon steel 0.3-10mm), 40L bottle can use 6.5hrs
3. Nitrogen cylinder(cut fine quality stainless steel , aluminum 0.3-4mm)
Cut thickenss Gas options 1500W(220v single phase):
1. >13bar air compressor (cut carbon steel 0.3-6mm , stainless steel,aluminum 0.3-6mm)
2. oxygen cylinder (cut carbon steel 0.3-16mm), 40L bottle can use 6.5hrs
3. Nitrogen cylinder(cut fine quality stainless steel , aluminum 0.3-6mm)
Cut thickenss Gas options 2000W(220v single phase):
1. >13bar air compressor (cut carbon steel 0.3-10mm , stainless steel,aluminum 0.3-8mm)
2. oxygen cylinder (cut carbon steel 0.3-20mm), 40L bottle can use 6.5hrs
3. Nitrogen cylinder (cut fine quality stainless steel , aluminum 0.3-8mm)
Cut thickenss Gas options 3000W(380v 3phase):
1. air compressor (cut carbon steel 0.3-12mm , stainless steel,aluminum 0.3-10mm)
2. oxygen cylinder (cut fine quality carbon steel 0.3-22mm), 40L bottle can use 6.5hrs
3. Nitrogen cylinder(cut fine quality stainless steel , aluminum 0.3-10mm)
Packing By sea:
1, CNC BEAMS 2600*450*600mm 120kg
2, RAILS 3580*280*185mm 100kg
3, Water chiller 510*410*500 60KG
Total 3pkgs 280kg 1cbm
Packing By air
1, CNC and rails 2600*450*600mm 220kg
2, Water chiller 510*410*500 60KG
Total 2pkgs 280kg 0.8cbm
